Sliding doors HiFinity

Unlimited view
Learn more
Top quality without compromise

Unlimited view

With the Hi-Finity system, users can enjoy an unobstructed view and an extremely efficient system solution. The strong design allows the installation of glass elements weighing up to 750kg and fixed elements weighing up to 1200kg. It provides excellent insulation through double and triple glazing, giving a sense of warmth and comfort. The Hi-Finity system is extremely energy-efficient, almost invisible and elegant, so it is perfect for modern, low-energy construction.
Download the brochure
Elegant lines and an unobstructed view
Ultimate design freedom, matching each project requirement
Floor-to-ceiling and wall-to-wall fully concealed profiles
Explore all variants

Infinite possibilities

01. Type

This is a threshold-free finish, in which the carriage is retracted under the floor and the floor covers the frame structure.

The open corner variant gives you much more design freedom and a more spacious feel.

The most economical and clean variant, in which all opening sashes slide into the wall.

02. Energy

The High Insulation variant can hold triple glazing (or thicker acoutstic double glazing), for and even better thermal and/or acoustic performance

03. Safety

The system is available in an anti-theft version for added peace of mind.

04. Other

In this variant, even more of the window can be opened, as all the sashes slide one behind the other.

Basic variant for single pane windows.

Product options

Glass Corner
Glass to glass connection without profiles obstructing the view
Zero Threshold
Entrance without boundaries, even with continuous flooring.
Access Control
Making your home smart and connected.
Motorised
Comfortable to use, even remotely.
Gutter
Better water performance, without adding thresholds.
Concealed Drainage
No more plastic cover caps, enjoy those clean lines.
Flyscreen
Enjoy cool summer evenings, without losing sleep.
Balustrade
Safety can equal beauty.
*Available options depend on the choice of profile and configuration. Please contact your Profal Kielce consultant.
  • WhatsApp Bussiness Support
Finishing options

Unparalleled range of colors and finish types

Looking for a different color?

You can choose from a palette of as many as 450 colors.
aluminiowe systemy okienne i drzwiowe
aluminiowe systemy okienne i drzwiowe
aluminiowe systemy okienne i drzwiowe
v
Specifications

Technical information

Thermal Insulation
Passive
Air-Water-Wind
High
Acoustics
Extreme
Rw(C;Ctr) = 46(-1;-3) dB
Burglary Resistance
High
PAS 24 - RC2
Max Weight
Vent = 750 kg
Fixed = 1200 kg

Performance

Energy

Thermal insulation
Uf = 0.8 W/m²K

Comfort

Air tightness
Class 4 (600Pa)
Water tightness
Class E750 (750Pa)
Wind load resistance
Class C5 (2000Pa)
Acoustics - Rw(C;Ctr)
46(-1;-3) dB
Opening & closing resistance regulation
Class 3

Safety

Burglar resistance
RC2- PAS 24

Properties

Max. dimensions & weight

Max. height of vent
4000 mm
Min. height of vent
1800 mm
Min. width of vent
1000 mm
Max. weight of vent
750 kg
Max. width of vent
3500 mm
Max. weight of fixed part
1200 kg

Sightlines

Min. width 4-pane
67 mm
Depth Vent
44 mm
Min. width meeting section
35 mm
Depth frame-vent
148 mm
Min. width T-profile
35 mm
Depth frame 2-rail
148 mm
Min. visible width (interior view)
8 mm
Depth frame 3-rail
236 mm
Min. visible width (exterior view)
8 mm
Depth frame 4-rail
325 mm
Min. height treshold
0 mm

Glazing

Rebate height
17 mm
Min. glass thickness - vent
36 mm
Glazing method
Envelope glazing - Structural Glued Glazing
Max. glass thickness - vent
54 mm

Panoramic windows in elegant black profile
