ConceptWall 86

Quick installation
Top quality without compromise

Quick installation

Curtain Wall 86, is an insulated, aesthetically pleasing curtain wall system that is ideal for large construction projects. With this type of project, what matters most is the quick installation of the system on site. Therefore, CW 86 offers a special solution in which cassettes or individual components can be pre-assembled already at the production facility.
At the construction site, these cassettes can be attached to a traditional post-and-beam structure (CW 86) or the façade can be built gradually, element by element, according to the modular curtain wall principle (CW 86-EF).
The CW 86 system is available in two versions of glazing with extraordinary aesthetic qualities: Cassette Glazing (CG), is a solution in which the panes are fixed with glazing beads, while in Structural Glazing (SG), the panes are structurally joined, creating a uniform glass surface on the outside of the building.
Systems with different energy efficiencies are available, including thermally insulated profiles designed for Structural Glazing. Thanks to the use of innovative water drainage methods, such as the cascade system, this facade meets the highest standards of watertightness and airtightness. Therefore, the system performs well in even the most extreme conditions, such as coastal areas or high altitudes.
In addition to the ability to easily combine different window, door and sunshade systems, CW 86 offers controllable solutions for opening elements such as clerestory windows and parallel extension windows, providing a complete façade solution for any building.

Top quality without compromise

Infinite possibilities

The element facade allows you to do most of the work in the workshop providing better precision. At the same time, it reduces the time spent on construction reducing costs.
All-glass curtain wall through the use of glass packages glued to the profiles.
Full personalization

Product options

Concealed drainage
No more plastic caps, enjoy a clean design.
Safety can go hand in hand with beauty.
Automatic drive
Convenient to use, even remotely.
Glass corner
A combination of two glass panes, without obscuring the view.
Finishing options

Unparalleled range of colors and finish types

Choose from a palette of
450 colors
Choose from a palette of
450 colors

Technical details

Thermal insulation

High Uf = 3.9 W/m²K


Extreme AE 700 (700Pa) / RE1050 (1050 Pa) / Class B5 (2000Pa)



Width Element

Min 500 mm
Max 2000 mm
